Active Key AK-S100/35

AK-S100/35

35 Key Programmable POS Keyboard

The AK-S100-UW-35 Series is a high quality, high reliable Point of Sale keyboard. An internal metal plate for key fixation and ESD protection grants long life expectancy and makes the keyboard extremely sturdy.

Each key can be programmed with user defined sequences of key codes. The programming tool Matrix Maker is included. No special driver software is required. All Keys can be programmed in 8 layers and keys can be assigned to switch layers.

AK-S100/35 IN THE ACTIVE KEY ONLINE-SHOP

DETACHABLE
KEY CAPS

There are detachable key cap sets for our programmable POS keyboards to inscribe the keys indivdually.

Active Key Taste mit Tastenkappe und Beschriftung
Active Key AK-100/24

Sample

VARIABLE KEY SIZES – FLEXIBLE USE

The keys can be cumulated to single keys (2 or 4 groupings). Therefore our programmable/POS keyboards are customizable and applicable in accordance with your purpose.

FEATURES

  • 35 Programmable Keys

  • Internal metalplate for key fixation

  • 50 million actuations per Key

  • Keys can be band together to groups of 2 or 4

Active Key AK-S100/35

PRODUCT IMAGES

SPECIFICATION

Compatibility

All systems supporting standard PS/2 or USB keyboards

Temperature Range

Storage: –40º to +60º C
Operation: 0º to +50º C

Power Supply

5 Volt +/- 5% via PS/2 or 5 Volt +5%/-10% via USB interface, current < 100mA

Interface

USB or PS/2 (depending on version)

Key Switch Technology

MX keys based on Gold Cross Point Technology

Lifetime Individual Key

> 50 million operations

Dimensions

198mm x 122mm x 45mm

Weight

0.45 kg

Available Accessories

2 x 1 keys, 2 x 2 keys

Characteristics

Metal Plate, Internal Memory

Agency Approvals

CE, RoHS

Download Datasheet

Download Datasheet for AK-S100/35 in PDF-Format

FURTHER INFORMATIONS

You can find our products in our Onlineshop.
If you have any questions, we would gladly provide personal advice.
